Sale

TOA F1300BT Wide-dispersion Speaker System 5 นิ้ว

ตู้ลำโพงแขวนผนังขนาด 5 นิ้ว 30 W 8 Ohm 70,100 V Line TOA F-1300BT Bass-reflex type Frequency Response 80 – 20,000 Hz, -10 dB Crossover Frequency 2 kHz

ราคาสินค้าเป็นราคาใบละ….ไม่รวมภาษีมูลค่าเพิ่ม…

฿4,820.00 ฿4,100.00

Quantity:

สอบถามและสั่งซื้อสินค้า

Category: . Tag: .

Product Description

TOA F1300BT Wide-dispersion Speaker System 30 W

ตู้ลำโพงแขวนผนังขนาด 5 นิ้ว 30 W 8 Ohm 70,100 V Line TOA F-1300BT Bass-reflex type Frequency Response 80 – 20,000 Hz, -10 dB Crossover Frequency 2 kHz

The F-1300 Series Speaker are compact two-way speaker systems designed for high efficiency, wide range, and high power input handling capability. These speaker systems can be installed in a manner ideal for the location and intended application.

Features:

  • Compact wide-dispersion speaker
  • Up to 150 W continuous program
  • Dispersion angle of 90° x 90°
  • 2-way speaker with high quality 13 cm woofer and balanced dome tweeter
  • Paintable
Share This:
Category: .  Tag: .

Specifications

Enclosure Bass-reflex type
Rated Input 30 W (high impedance)
Power Handling Capacity Continuos pink noise: 50 W (low impedance)
Continuos program: 150 W (low impedance)
Rated Impedance 8 Ω
100 V line: 330 Ω (30 W), 1 kΩ (10 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
70 V line: 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W)
Sensitivity 90 dB (1 W, 1 m) at installation in 1/2 free sound field
Frequency Response 80 Hz – 20 kHz, -10 dB at installation in 1/2 free sound field
Crossover Frequency 2 kHz
Directivity Angle Horizontal: 110゜, Vertical: 100゜
Speaker Component Low frequency: 13 cm (5″) cone-type
High frequency: 25 mm (1″) dome tweeter
Input Terminal Push-in terminal
Finish Enclosure: HIPS, black
Punched net: Surface-treated steel plate, black, paint
Joint bracket, wall bracket: Steel plate, t1.6, black, paint
Speaker bracket: Die-cast aluminum, black, paint
Dimensions 162 (W) × 250 (H) × 161 (D) mm (6.38″ × 9.84″ × 6.34″)
Weight 3.6 kg (7.94 lb) (including the supplied brackets)
Accessory Speaker bracket…1, Joint bracket…1, Wall bracket…1, Bracket fixing screw…1 set
Option Board hanger bracket: HY-BH10B,
Ceiling mount bracket: HY-CM10B (used for the horizontal speaker mounting),
Cluster bracket: HY-CL10B, Speaker stand: ST-16A
